1. High Performance: Professional wind direction sensor, better linearity, high accuracy, no dead spot, strong to thunderstrike, easy to observe, stable and .
2. Accuracy And Design: 360° wind direction sensor adopts accuracy angle sensor inside, accurate measurement. Easy to install, designed with a fixed south line, easy to use.
3. Premium Materials: This anemometer instrument uses low inertia ABS wind vane to respond to the wind direction, better dynamic characteristics, not easy to damage, bring you a better using experience.
4. Working Principle: Wind direction anemometer is mainly used to measure the wind direction, its working principle is usually based on the rotating type, which can accurately measure the wind direction.
5. Applicable Fields: This instrument is commonly used in meteorology, environmental monitoring, aerospace and other fields to understand the wind situation and make corresponding countermeasures.
Specification:
Item Type: Wind Direction Sensor
Material: ABS
Size: Approx. 223 x 190 x 70mm / 8.8 x 7.5 x 2.8in
Gross Weight: Approx. 375g / 13.2oz
Output: RS485 for Modbus
Measuring Range: 0‑359° All Round
Extension Line Length: 0.8m / 2.6ft
Accuracy: Full Range: ±3 Degree
Resolution: Full Range: 1 Degree
Starting Wind Speed: ≤0.8m/s
Maximum Power Consumption: 0.48W
Load Capacity: DC12V Power Supply, Current Output Impedance ≤350Ω, DC24V Power Supply, Current Output Impedance ≤900Ω
Operating Environment: Temperature -35℃-60℃, Humidity ≤100%RH No Condensation
Level: IP64
Wide Application: Suitable for Wind Direction Measurement in Gardens, Greenhouses, Weather Stations, Ships, Docks, Aquaculture, Advertising Barriers, Meteorology, Marine, Environmental, Airports, Ports, Laboratories, , And Transportation Environments
Installation Aperture: 3.2mm / 0.1in
Aerial
