1. [Input and output voltage] The high voltage module supports an entry of 12-36 V CC (it is recommended 24 V) and emits a high voltage CC voltage with an input voltage of approximately 1000 times.

2. [Input performance] The 12 V entrance of the high voltage coil module can be up to 50-100 w of power, the input of 24 v can be up to 200 w or more, so it is better to request the power of the power supply through 10 A.

3. ZVS High Voltage Performance Module with ZVS voltage transmission circuit with steering wheel transmission circuit for the ignition coil unit, by the majority of enthusiasts also known as ZVS circuit.

4. [Application] ZVS module with high performance, under heat development, simple and reliable, generalized to boost sparks (for SGTC) and for the manager of, for Marx generators, etc.

5. [Use the electricity requirements] The heating power supply module uses a 12-24 V-DC input and requires a power supply current of at least 4 to 12 V and at least 8 to 24 V.

6. [Power supply] It can be supplied with electricity through a switching power supply, a battery, a or a high performance transformer to align it and filter it yourself, and the filter capacitor does not have less than 10,000 UF.

Technical data:

Article type: ZVS module

Material: PCB

With 12 V input voltage

Output voltage: 10000 V

Maximum performance: 100 w

With input voltage 24 V

Output voltage: 20,000 V

Maximum performance: 200 w

How to use:

Use after installation.

Packaging list:

1 x ZVS module
