Wifi Battery Monitor with Shunt, 10-100V 0-50A Bidirectional Detection Remote Monitoring Battery Monitor with 2.4 Inch Color LCD Screen

Wifi Battery Monitor with Shunt, 10-100V 0-50A Bidirectional Detection Remote Monitoring Battery Monitor with 2.4 Inch Color LCD Screen

Brand: Jectse
4.9
A$94.50
Availability:
  • In Stock
  • [Built in Reminder] With a built in reminder, you can set low capacity or low voltage reminders. Once the values fall below the preset levels, the buzzer will sound immediately, accompanied by a pop up reminder, allowing you to stay informed of the device status.
  • [Multiple Parameter Measurements] This battery monitor can measure voltage, current, power, charge discharge capacity, watt hour, time, and other physical parameters. Set parameters to enable functions such as overvoltage, undervoltage, overcurrent, overpower, overtemperature, and time limited protections.
  • [Wide Battery Compatibility] Compatible with various types of batteries including VRLA, LFP, Li Ion, NI MH, and other battery types within the voltage range of 10 to 100V.
  • [Remote Monitoring] The battery monitor supports real time remote monitoring via WiFi, , and APP connectivity. Keep track of your battery status anytime, anywhere by staying connected to the battery monitor from your smartphone or other devices.
  • [Enhanced User Interface] Featuring 2.4 inch HD color LCD screen with optimized interface, offering larger, clearer text. With dark and light mode options, ensuring easy visibility of information. The silicone key provides smoothly operations, fast response, and comfortable touch.

Product Description

Multi-application

Compatible with lead-acid, lithium iron phosphate, lithium-ion, nickel-metal hydride batteries and other types of batteries, as long as the voltage of the battery in the measurement range of 10-100V are all applicable.

Real-time display, accurate measurement

Measure voltage, current, power, charge/discharge capacity, watt-hour, time and other physical parameters. Setting parameters to realize over-voltage protection, under-voltage protection, over-current protection, over-power protection, over-temperature protection, time-limit protection and other multiple protection functions.

Multiple control methods

Cell phone APP control

1、Support Bluetooth connection

2、Support Wifi connection

3、Support remote connection

Display control

1.Monitor control and display data

Automatic identification of current direction

Automatically recognizes and monitors the current in both charging and discharging directions.

When both charging and discharging are crossing the line at the same time, the display shows the difference between the charging current and discharging current at the same time.

Built-in buzzer for intelligent monitoring

After setting the low battery or low voltage alarm, once the value is lower than the preset value, the buzzer will sound immediately, and the pop-up window will remind you, so that you can always grasp the status of the device and avoid accidents.

No Data Loss in Power Failure

No fear of accidental power failure, after the power failure and incoming call, it will continue to run according to the settings before the power failure.

Before first use, the battery effective capacity and current remaining battery percentage must be correctly set. If the effective capacity of the battery or the current remaining battery percentage is unknown, follow the steps below to check:

  • 1. Charge the battery pack completely.
  • 2. Input preset battery capacity setting in the system settings, for example, if the rated battery capacity is 150AH, we set 150AH as the preset battery capacity. (You can check the rated capacity on the battery nameplate).
  • 3. Set the remaining capacity percentage to 100%, then discharge the battery pack.
  • 4. After discharge, the remaining capacity value displayed on the display is 10AH. The actual battery capacity is 140AH (150 minus 10), which means the battery has discharged a total of 140AH and cannot be completely discharged. Therefore, we set the actual discharged capacity of 140AH as the preset capacity and set the capacity percentage to 0%. This completes the battery setup.

Specification

  • Item Type: WiFi Battery Monitor
  • Material: ABS
  • Model: KM105F
  • Screen Size: 2.4 Inch
  • Sampling Method: Shunt
  • Voltage Testing Range: 10-100V
  • Current Testing Range: 0-50A
  • Current Resolution: 0.001A
  • Capacity Display Range: 0-100%
  • Power Testing Range: 0-5KW
  • Power Resolution: 0.0001W
  • Ampere Hour Testing Range: 0-9999.9Ah
  • Capacity Resolution: 0.001Ah
  • Bluetooth Connection Distance: Up to 10 Meters Unobstructed
  • WiFi Connection Distance: Up to 10 Meters Unobstructed
  • Remote Connection Range: Global
  • Voltage Accuracy: ±5%+0.02V
  • Current Accuracy: ±2+0.002A
  • Sampling Rate: 5 Times/Second
  • Display Power Consumption: 0.9W
  • Screen Off Time: 10S, 20S, 30S, 40S, 50S, 60S, AUTO (During discharge, screen stays on when I≥15mA, screen off when I<15mA and time>20s)

How to Use

  • Follow the instructions manual.

Package List

  • 1 x WiFi Battery Monitor
  • 1 x Shunt
  • 1 x 1m Red Positive Wire
  • 1 x 5m Communication Wire
  • 1 x User Manual
  • Item Model Number: Jectserudys92ktc
  • Country of origin: China
  • Package Dimensions: 17 x 15 x 6 cm; 331 Grams
  • Manufacturer: Jectse
