High sensitive response circuit breaker changeover, manual transfer switch power transfer switch, dual power electrical selector switches din rail mount, dual power automatic transfer switch tool 2p 63a generator circuit fast changeover controller millisecond switching.

Rated Current In: 63A

Insulation Voltage Ui: 690VAC

Grade: PC

Frequency: 50/60Hz

Standard: IEC60947-6

Rated Short Circuit Current Limit(RT16-00/63A): 50KA

Package List:

1 x Dual Power Automatic Transfer Switch

Note:

Maintenance and inspection should be carried out by professionals.

1. To ensure the good performance of the ATS, the first maintenance and inspection should be conducted within 6 months of use. Subsequently, maintenance and inspection should be performed at least once a year. In harsh installation conditions, the frequency of maintenance and inspection should be increased.

2. Check for deformation and damage to electrical parts, and clean the.

3. Metal particles and local burning. , oxidation, and dust on the can result in poor , so manual and measurement of the necessary should be performed.

4. If the ATS is damp or has not been used for a long time, dry before connecting the power. After removing dust, use a 500V megohmmeter to measure the insulation of the normal power source and the AC power source. The insulation , including the load side and both poles, should not be less than 10MQ when using live parts and metal plates.
