1. It help extend battery life
2. Universal 12V applications
3. Prevents primary battery discharge
4. Made of water resistant black phenolic plastic
5. The main function of this product is to switch on, it can be used alone, it can be also connected to control to use
Spec:
Features:
It help extend battery life.
Universal 12V applications.
Prevents primary battery discharge.
Made of water resistant black phenolic plastic.
The main function of this product is to switch on, it can be used alone, it can be also connected to control to use, but this product does not include additional control relay, and if the controller is connected, it mainly used in the dual battery.
Specifications:
Product series: auto relay
load: high power
switching current: 500A
switching voltage: 7.8VDC
form: transformation type
Rated current: 500A
Protective features: sealing type
Coil power: 12V DC
Weight: 235g
DATA
materialAgSn0_27In_20_33
form1H(1A)
Ratings500A
Resistance100mMax at 6VDC 1 A
Max Switching Current 500A
Max Switching Voltage14VDC
Max Switching Power 500A
Life Expectancy Electrical100,000 Operations(at 30 Operations/minute)
Life Expectancy Mechanic10,000,000 Operations
COIL SPECIFICATION
Nominal Voltage (VDC)Coil ()Max Operate Voltage (VDC)Mix Release Voltage (VDC)Max Applicable Voltage (VDC)
121681.214
9CHARACTERISTICS:
Temperature Range-30~80℃
Vibration Resistance10-55Hz,1.5mm
Shock Operations Extremes Damage Limits 50g
100g
Humidity40-85%
Insulation Resistance100mΩ min at 500vdc
Safety Standard
Dielectric Strength Between Open Contacts2000VAC(for 1 minuter/s)
Between Contacts and coil1500VAC(for 1
