ELECTRICAL PARAMETERS
Static power consumption: ≤50mA
Battery Type: USE/FLD/GEL/LI/SLD(Default)
System voltage: 12V/24V
Battery's operating voltage range: 8V-32V
Rated charging current: 60A
Maximum PV Input Current: 53A
Maximum solar panel power: 800W/12V; 1600W/24V
Maximum PV open-circuit voltage: 150V
MPPT operating voltage point range: (Battery Voltage +2)~110V
MPPT tracking efficiency: >99%
Charging conversion efficiency: 85%-98% (10%-100% of rated power)
Rated load current: 40A
Load operating mode: Pure light-dependent control, light and time-dependent control, manual mode (default), debugging mode, normally opened.
TTL communication: Baud Rate 9600kps
RS485 communication: 2 isolated RS485 communication ports,
supporting parallel use, with power output of 5V200mA, baud rate of 9,600kps by default and adjustable.
Bluetooth communication: Built-in
CAN communication: RV-C Protocol
Historical data: Can store historical data of the past 300 days
Backlight function: Light up if the key is pressed down, and automatically turn off in 20s if there is no key action
Grounding type: Co-negative design and negative grounding
Cooling mode: Natural Cooling
Parallel connection for charging: Yes
Charging voltage line loss compensation: Yes
Support full settings: Yes
Constant voltage output setting: Yes
Charging temperature compensation of lead-acid battery: Yes
Temperature protection: Yes
Overload/short-circuit protection: Yes
Load pre-start: Yes
ENVIRONMENTAL DATA
Protection grade: IP32
Operating ambient temperature range: -35℃~ 65℃ (no derating within 45℃ if well ventilated)
MECHANICAL SPECIFICATIONS
Dimension: 260x216x98.5mm
Mounting hole spacing: 200 mm
Weight: 3.4kg
Fixed hole position: φ10mm
Additional Bluetooth module is required to achieve Bluetooth functionality.
