Features
Ultra Quiet: This module allows noiseless, high accuracy chopping algorithms for silent motor movement and silent standstill, making it super quiet during the printing process.
Powerful: This stepper motor driver module has better heat dissipation, supports higher currents and supports sensorless functions.
Replacement: This driver has all the features of the TMC2208 and is a complete replacement for the TMC2208.
Outstanding Performance: With an RDSon value of 0.2A, the TMC2209 driver has a lower resistively conducted output driver, providing lower power consumption and higher current.
Exquisite Design: Uart mode is supported by applying jumper caps instead of soldering for MKS gen lV2.0, skr1.3 1.4, for MKS sgen l.
Specification
Item Type: Stepper Motor Driver
Material: PCB, aluminum alloy
Model: TMC2209 V2.0
Microsteps: 256 subdivisions
Drive Current: 2.8A
Configuration: STEP, DIR or UART
Default Factory Current: 0.85A
Load Drive Motor Voltage: 5.5-28V
IC Logic Operating Voltage: 3-5V
Product Application: Various 3D main control boards
Recommended Current: No more than 1.7A
How to Use
Refer to the instructions for use
Package List
5 x Stepper Motor Driver
5 x Heat Sink
Note
1. Verf measures the voltage of Gnd and potentiometer.
2. Please do not connect the motor when measuring the voltage, otherwise the driver will be easily burned out.
3. Please connect the power supply when measuring the voltage, not just the USB power supply.
4. Please pay attention to the direction, please do not insert by mistake!
