Waveshare Industrial 8-Ch Analog Acquisition Module, 12-Bit High-Precision, Supports Voltage and Current Acquisition, DC 7~36V Wide Voltage Power Supply, 8-Ch Current Mode, 0~20Ma

Waveshare Industrial 8-Ch Analog Acquisition Module, 12-Bit High-Precision, Supports Voltage and Current Acquisition, DC 7~36V Wide Voltage Power Supply, 8-Ch Current Mode, 0~20Ma

Brand: Waveshare
5.0
A$60.90
Availability:
  • In Stock

Shop with confidence

Secure transaction Returns Policy Shipping to Australia
  • 8-ch current mode, 0~20mA
  • Configurable device address (1~255), multi devices can be cascaded on RS485 bus. bOnboard voltage regulator, supports 7~36V wide range power supply. Onboard unibody power supply isolation, provides stable isolated voltage, needs no extra power supply for the isolated terminal
  • Onboard unibody magnetical isolation, allows signal isolation, high reliability, strong anti-interference. Onboard resettable fuse and TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit, provides over-current/over-voltage proof, lightningproof & anti-electrostatic
  • Supports 12-bit high-precision acquisition with multiple range input modes, supports single-ended/differential input, supports voltage and current simultaneous acquisition. Adopts high-precision resistors and zero-drift high-precision operational amplifier for more accurate data acquisition
  • Built-in oversampling digital filtering algorithm, onboard watchdog, for stable output without crashing. Rail-mount case design, support stacking combination, easy to install and safer to use. 3x LEDs for indicating the MCU status and signal transceiving status
  • Item Model Number: Modbus RTU Analog Output 8CH (B)
  • Part Number: Modbus RTU Analog Input 8CH
  • Batteries Included: No
  • Batteries Required: No
  • Brand: Waveshare
  • Item Weight: 140 g
  • Model: Modbus RTU Analog Output 8CH (B)
  • Form Factor: rectangular
  • Package Dimensions: 12 x 8 x 4 cm; 140 Grams
  • Manufacturer: Waveshare
