Anern 6200W MPPT Hybrid Solar Inverter 48V off Grid 230Vac Pure Sine Wave with 120A Charge Controller - Multifunctional Wifi Support

Anern 6200W MPPT Hybrid Solar Inverter 48V off Grid 230Vac Pure Sine Wave with 120A Charge Controller - Multifunctional Wifi Support

Brand: Anern
5.0
A$891.45
Availability:
  • This item is currently not available

Shop with confidence

Secure transaction Returns Policy Shipping to Australia
  • 【PURE SINE WAVE INVERTER】6200W Off-Grid Solar Inverter, 48V, Built-in 120A MPPT Charge Controller, Pure Sine Wave Inverter, Single-phase Output 230VAC. This new 6.2kw All-In-One inverter combines the functions of an inverter, solar charger, and battery charger, offering uninterrupted power support in a single package. The inverter supports operation without a battery.
  • 【TECHNICAL SPECIFICATIONS】6200W hybrid solar inverter 48V DC to 220V/230V AC with 120A MPPT solar controller. Max.PV array open circuit vlotage: 450Vdc; Max. PV array power: 6500W; Max PV no-load voltage: 500Vdc; Maximum PV charging current: 120Amp; Rated output current: 44.3Amp.
  • 【RESTORE DEFAULT SETTINGS】Anern Solar Inverter has Overload/Over temperature/Short circuit protection. Smart design for optimizing battery performance. Intelligent variable speed fan efficiently dissipate heat and extend system life. Compatible to mains voltage or generator power, Automatic restart when AC power is restored.
  • 【MULTIPLE CHARGING & OUTPUT MODES】 4 charging modes are optional: solar, solar and utility only, solar priority; 3 Output modes: solar priority, utility priority, SBU mode. The solar inverter provides multiple charging and output modes to meet different user application requirements.
  • 【DIVERSIFIES USES】With both on-grid and off-grid working modes, you can utilize the inverter as an energy storage device even without a power grid (off-grid). Additionally, you may also wish to utilize it to reduce your household electricity bill (on-grid). It can accommodate various household and office loads, including refrigerators, lamps, televisions, fans, air conditioning, and other loads. The inverter supports four charging modes: utility first, solar first, solar & utility, and battery & solar.

Product Description

The ECO 6.2KW inverter has two AC outputs and one PV input, a new colour display for easier operation, the inverter is single-phase, does not support multi-phase or three-phase inverters, and does not support parallel connection.

Indicator Light

Easy Installation

Product Overview

AC INPUT 230Vac
Output frequency 50Hz/60Hz (automatic detection)
Maximum efficiency 98%
Nominal output power 6200W
Waveform Pure sine wave
Battery voltage 48VDC
Nominal PV voltage 360Vdc
MPPT PV voltage range 90-450Vdc
Maximum PV voltage 500Vdc
Minimum PV voltage 120Vdc
Maximum charge time AC+PV 120A
Accreditation CE
No-load power consumption >50W
Operating temperature -10°C bis 50°C
Dimensions (D*W*H) 450*350*110mm
Net weight 10KG

Q: Can the inverter communicate with the batteries?

A: Our inverters can only communicate with our brand's lithium batteries, not with other batteries.

Q: What types of batteries can be used?

A: Supports lead-acid, gel and lithium batteries.The default setting is to connect the battery, set item 05 as USE according to the manual, then adjust the lithium battery parameters from items 26/27/29

Q: Which battery sizes can be connected? Are there capacity requirements?

A: 6.2KW connect four 12 V batteries, no less than 100AH, to prevent the low power from starting the machine, 200AH is recommended.

Q: How many solar modules should be connected? What is the recommended input voltage?

A: The maximum input voltage is 500Vdc, the nominal voltage is 120Vdc-450Vdc; due to light duration and external factors, an input voltage of 300Vdc-400Vdc is recommended for normal start-up.

Q: What is a double AC output?

A: Primary and secondary outputs are normally used in normal situations, when there is no photovoltaic or grid power, the primary circuit is switched off and only the secondary output is maintained to save energy.

  • Item Model Number: AN-SCI-ECO-6200W-WIFI
  • Display Type: LED
  • Number of items: 5
  • Power Source: Solar and Battery Powered
  • Brand: Anern
  • Model Name: 6200W MPPT Hybrid Solar Inverter
  • Model: AN-SCI-ECO-6200W-WIFI
  • Wattage: 6200 watts
  • Manufacturer: Anern
