Features:
Suitable for range hood, nesting machine, smart equipment, entertainment equipment.
The motor is powered by easy-to-access 24V power supply.
Ball accurate gears, better performance than ordinary metal gears, resistant to stalling and no teething stuck.
Low noise, all metal gears, high torsion and fine workmanship.
Fine craftsmanship and well-selected material prolongs the motor's service life.
Specification:
Voltage :DC24V
Using Voltage Range: DC12~30V
Voltage/V：24 24 24 24 24 24 24 24 24
Speed /RPM(Optional)：150 100 50 40 30 25 20 10 5
Rated /Kg.cm:0.2 0.5 0.7 2 5.3 6.7 9 15.9 26.5
Rated current /A:≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3 ≤0.3
Maximum /Kg.cm:0.9 1.6 2 7.5 10 13 18 30 45
Stop current /A:0.85 0.85 0.85 0.85 0.85 0.85 0.85 0.85 0.85
Package List:
1 x Motor
