DIGISHUO 4Pcs L298N Motor Driver Controller Board Module | Stepper Motor DC Dual H-Bridge for Arduino Smart Car Power UNO MEGA R3 Mega2560
DIGISHUO 4Pcs L298N Motor Driver Controller Board Module | Stepper Motor DC Dual H-Bridge for Arduino Smart Car Power UNO MEGA R3 Mega2560
Brand: DIGISHUO
A$21.65
- ※L298N as main driver chip makes strong driving ability/small heating/strong anti-interference/low calorific value
- ※Dual-channel H-bridge driver working mode creates higher working efficiency
- ※To avoid damage the voltage stabilizing chip, please use an external 5V logic supply when using more than 12V driving voltage
- ※Use large-capacity filter capacitors and diode with freewheeling protection function, increasing reliability
- ※Large capacity filter capacitance, afterflow protection diode, more stable and reliable
Product Description
Note:
- General Application: When your driver is 7V-12V, you can enable the on-board 5V logic supply. When using the on-board 5V power supply, the + 5V power supply in the interface does not input voltage, but it can draw 5V voltage for external use.
- Unconventional application of high-voltage drive: When the driving voltage is higher than 12V, less than or equal to 24V, for example, to drive a motor with rated voltage of 18V, the jumper cap with 5V output enabled on-board voltage must be pulled out and then outside the 5V output port Connect 5V voltage to L298N internal logic voltage supply.
| Chip： | ST L298N dual H-bridge driver chip |
| Logic voltage： | 5V |
| Logic current： | 0mA-36mA |
| Storage Temperature： | -20 ¡æ to +135 ¡æ |
| Operating mode： | H-bridge driver (dual) |
| Drive voltage： | 5V-35V |
| Drive current： | 2A (MAX single bridge) |
| Maximum power： | 25W |
Two ways to turn the system back on:
- Flip the power switch on the back of the computer and wait for the power supply cap to discharge as the relay will reset without power.
- After popping the hood and examining for faults, press the button on the relay.There is a red LED on this for power and a green LED to indicate the relay is activated, so you can be pretty sure what state this is in . Any time you are trying to hot wire an ATX power supply and you need a toggle function besides the switch in the back, just needs power from pin 9, the relay connected to pin 16 and then of course connections back to ground pin(s).
Product size：
- Driver Board Size：55mm*60mm*30mm
- Driver Board Weight:33g
- Size: 43x43x27mm
Package Included
- 4Pcs L298N Motor Driver controller Board Module
- Item Model Number: L298N
- Part Number: L298N
- Number of items: 4
- Graphics Card Interface: Integrated
- Batteries Required: No
- Brand: DIGISHUO
- Compatible Devices: Personal Computer
- Item Weight: 130 g
- Number of Ports: 1
- Voltage: 5 Volts (DC)
- Model Name: L298N
- Model: L298N
- Product dimensions: 4.3 x 4.3 x 2.7 cm; 130 Grams
- Manufacturer: DIGISHUO
