DIGISHUO DC 24V 5A 120W Power Supply Adapter Transformer Switch AC 240V to DC 24V 5Amp Switching Converter LED Driver for LED Strip Light CCTV Camera Security System

DIGISHUO DC 24V 5A 120W Power Supply Adapter Transformer Switch AC 240V to DC 24V 5Amp Switching Converter LED Driver for LED Strip Light CCTV Camera Security System

Brand: DIGISHUO
5.0
A$18.80
Availability:
  • This item is currently not available

Shop with confidence

Secure transaction Returns Policy Shipping to Australia
  • [24V 5A Power Supply] Input: AC 240V 50/60Hz Output:DC 24V Max 5A 120W. Two output ports. Each port outputs 0~5A automatically to match your device, 10A max in total for 2 ports. The default output voltage is 24V, but it can be regulated by 5%, from 23.7V to 24.3V
  • [Supply less than 5A such as 1A, 2A, 3A, 4A, 5A] For example, if your device draws 7.5A, then 7.5A will be supplied. If draws more than 10A, only 10A will be supplied and power supply will be damaged soon. NEVER OVERLOAD
  • [Widely Application]Great for LED Strips,3D Printer,ham radio transceiver,CCTV cameras,car subwoofer amp,audio amplifier,wireless router,ADSL Cats,HUB,audio/ video power supply etc
  • [Protection]Shortage Protection, Overload Protection, Over Voltage Protection
  • [Metal Case Protection]Maximum protection but IN-DOOR USE ONLY!

※100% full load burn-in test

※Universal AC input / full range

※It's good quality & high performance

※Input: AC110-265V 50/60Hz

※Out put: DC 24V

※Protections: overload/ over voltage/ short circuit

※Cooling by free air convection

(Not suggest for use in bathroom)

※Connection:

※L/N: AC power input

※GND: DC power output "-"

※V: DC power output "+"

※+V / ADJ: Adjust the output voltage

※Safety Compliance: CCC/ FCC / CE

※Working Temperature: 0~40℃

※Storage Temperature: -20~60℃

※Ambient Humidity: 0~95% Non-Condensation

※Compatible with 3528, 2835 ,3014, 5050, 5630 ,5730 Led strip lights

How to calculate Support max LED Strip Length

Assumption: Your LED Strip 60LEDs/m, and each LED 0.2W,

then calculate max LED Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 24W(this listing)÷12W/m=2m

So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=2m light

Feature

Voltage Current Power Size mm

24V 5A 120W 159*98*42

24V 5A 120W 198*98*42

24V 8.3A 200W 199*110*50

24V 10A 240W 199*110*50

24V 15A 360W 215*115*50

24V 20A 480W 215*115*50

24V 21A 500W 215*115*50

24V 30A 720W 241*125*65

You'll Receive

1Pcs Switch Power Supply Adapter for LED Strip

  • Item Model Number: S-120-24
  • Part Number: S-120-24
  • Batteries Included: No
  • Batteries Required: No
  • Wattage: 120 watts
  • UPC: 768161772197
  • Item Weight: 480 g
  • Model: S-120-24
  • Specification met: CE
  • Package Dimensions: 21 x 10 x 5 cm; 480 Grams
  • Does it contain liquid?: No
  • Manufacturer: DIGISHUO
