TFM-200 Fiber Conncetor Inspection Microscope

1.Strictly inspect the polishing quality with Optical Magnification: 200x

2.Adapter: 1.25 mm & 2.5mm adapter/ Interface: SC, FC, ST and LC

3.Inspect fiber optic terminals. This utilizes white LEDs for coaxial illumination and provides the most suitable ferrule end view. It has good optical performance and an integrated laser safety filter, which can produce excellent scratches and contamination details

4.Momentary button on/off switch. Long life, durable and reliable. With a multi-function adapter interface. Provides clear and bright images and smooth focus control

5.The products pass strict quality and safety standards to ensure long service life and trouble-free. Equipped with LED lighting and laser filter installed to protect the eyes, long-term use does not hurt the eyes

TPM-25 Optical Power Meter

1.Wavelength: 800 ~1700 nm

2.Measurement Range: -70~+10 dBm

3.Standard wavelength: 850,980,1300,1310,1490,1550,1625(nm)

4.Connector: 2.5mm universal

5.Power supply: 2* AAA 1.5V batteries(Package not included the batteries because the airline not allow to put it into)

6. 20h operation time and machine can auto shutdown in 10 mins to save the power

TLS-25 Optical Light Source

1.Wavelength: 1310/1550nm

2.Output Power: -5dB

3.Output Stability: ±0.05dB/15mins; ±0.1dB/ 8hours

4.Connector: SC+2.5mm universal+ (1.25mm for LC is Optional)

5.Frequencies: CW, 270Hz, 1KHz, 2KHz

6.Power Supply: 2*AAA 1.5V batteries(Package not included the batteries because the airline not allow to put it into)

7. Protective cover, shockproof and anti-fall

TFL-Q-10mW VFL

1.Modle: VFL TFL-Q 10mW

2.Testing distance: 8~10km

3.Working time: 10h

4.Wavelength Range: 650nm

5.Frequency: cW/2Hz

6.Power Supply: 2*AAA 1.5V batteries(Package not included the batteries because the airline not allow to put it into)

7. Light and small(Dimension: 93* 46.5*21mm, 61g). This little device could be hung onto the carry bag or with the belt

TOC-250/TOC125 One-click Fiber Optia Cleaner

1.TOC-250 for 2.5mm SC/ST/FC/E2000(APC & UPC), TOC125 for 1.25mm LC/MU (APC & UPC)

2.More than 800 cleaning times, with 1s push, just a glimpse make clean fiber optical fiber end face, fast, cost-effective and efficient.

3.Effectively cleaning differnet dirty--180°spin cleaning, effectively clean 99% stains. Good at cleaning hard-to-reach areas, ferrule end-faces and inside the plug within fiber optics connectors.

4.With the duct cap to avoid the pollution. At the same time, they are made of anti- static resin raw materials, dust-free cleaning filament and cleaning reagents to ensure the products not polluted by dust

TCC-600 Optic Cassette Cleaner

1.For cleaning the end face ofFC/SC/LC/ST/MU/D4/DIN optical fiberconnector PC/APC

2.Provides 500+times of cleaning

3.Cleaning belt is made of high density textile

4.Hand control operation, lightweight design, replaceable core

FOCP Fiber Optical Cleaning Platform

1.For cleaning FC/SC/LC/ST/bare fiber / machine

2.Size: 76*76*76mm/180 pieces

3.Material: Dust-free and lint-free wiper
