Feature:
1. Come with very reliable in performance thanks to the spacer‑type spool valve structure
2. Possess many other features in addition to reliable performance, so have a wide range of applications in many fields
3. In the structural design of the , there are automatic compensation function for seal wear
4. can meet the needs of large media, has become the choice of most users in the working medium. Has a larger capacity than the Q series solenoid valve
5. product has a compact structure, the base plate uses a takeover structure, which makes installation and maintenance work more convenient
Specification:
Item Type: Electric Solenoid Valve
Material: Aluminum alloy
Model: K25DH-15
Interface Diameter (inch):G1/2
Pressure: 0.15～0.8 (mpa)
Reversing Time (s): ≤0.08
Maximum Allowable Commutation Frequency (Hz): 6
DischargeRate (cm³/min): 100
Environmental Temperature (℃): -5~50
Medium Temperature (℃): -5~50
Life (thousand times): ≥1500
How to use:
1. During debugging or power failure, manual operation can be used (manual switch 0 position is off, 1 position is on).
2. The inside and outside of the pipe must be cleaned during installation, and then the dust cap must be removed.
3. Suitable to disassemble and wash or add some lubricating oil for long storage time or long-term use or unskilled action.
Package List:
1 x Electric Solenoid Valve
