Note: This smart touch panel switch could work with or without neutral wire, if there is no neutral wire, just add the capacitor(in the package); How to connect the smart switch to Smart Life App:
1. Download the App “Smart Life”;
2. Long press one of the on/off button until the blue wifi indicator blinks quickly.
3. Then open smart Life APP tap “+”and select "wifi switch”to add.
4. Choose 2.4ghz wifi router user name and password;
5. Confirm wifi indicator on smart light switch rapidly blink， tap “Next” on smart phone screen;
Caution
1.Keep The Power Off Until You Finish The Installation Otherwise The Switch May Fail.
2.For no neutral switch, The Wifi Switch capacitor(inside the box) Should Be Installed To The Terminal "L1".
3.WiFi Switch ONLY works with a 2.4GHz wifi networks when connecting to the app.
Voltage: AC 100-240V 50/60Hz
Rated Current: 10A
Power: 300W/Gang
Gang: 1-Gang / 2-Gang / 3-Gang
Standby power consumption: 0.5W/Hour
Working Temperature: -20°C - 50°C
Working humidity: 5%-95% RH，non-condensing
WIFI Standard: IEEE 802.11bgn 2.4GHz
Network Security: WPA/WPA2”
Dimension: 86*86*40mm
Hub requirement: No
Control Mode: APP/Manual
Installation method: Embedded（86type）EU UK mounting box
Voice Control: Compatible with Alexa、Works with Google Assistant、SmartThings
APP: TuyaSmart/Smart Life
