Feature:

• Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches, and a 2MB shared L3 cache
• VideoCore VII GPU, supporting OpenGL ES 3.1, Vulkan 1.2
• Dual 4Kp60 HDMI display output with HDR support
• 4Kp60 HEVC decoder
• LPDDR4X-4267 SDRAM
• Dual-band 802.11ac Wi-Fi
• Bluetooth 5.0 / Bluetooth Low Energy (BLE)
• microSD card slot, with support for high-speed SDR104 mode
• 2x USB 3.0 ports, supporting simultaneous 5Gbps operation/2x USB 2.0 ports
• Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT)
• 2× 4-lane MIPI camera/display transceivers
• PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter)
• 5V/5A DC power via USB-C, with Power Delivery support
• Real-time clock (RTC), powered by an external battery

USB 3.0

• Upgraded USB capacity: two USB 2 port+USB 3 ports, which can transfer data up to ten times faster.

Dual 4Kp60

• Raspberry Pi 5 can drive dual 4Kp60 displays and has 4Kp60 HEVC decoding hardware functionality. This upgrade has led to a qualitative leap in performance compared to the previous generation of products.

RP1

• Raspberry Pi 5 is built using the RP1 I/O controller, a package containing silicon designed in-house at Raspberry Pi.

Power button

• Power button on the board for the first time as raspberry PI series/Power control can be more easily and safely.

Real-time clock

• Provide a "real-time clock" module on the board, which provides a time holding function that has so far had to rely on external modules.

By connecting the battery, the Raspberry Pi can maintain time even without power, making it more convenient.
